Prestressed steel strand

Product Name:Prestressed steel strand


Introduction: Prestressed steel strands are mainly used for the reinforcement of prestressed concrete structures. Such as the construction of bridges, crane beams, geotechnical anchoring projects for large-span railways and highways, as well as multi story industrial plants, coal mines, sports venues, etc. There are two types of surfaces: bonded and non bonded. Divided into 4 different structures: 1x2 (2 shares), 1x3 (3 shares), 1x7 (7 shares), and 1x19 (19 shares). Main execution standards: GB/T5224、 American standard ASTMA416, British standard BS5896 Japanese standard JISG3536, international standard ISO6934, European standard EN10138, or supply according to the technical agreement agreed upon by both parties.

Product Parameters


Available nominal diameter specifications
1x2: 5mm,5.8mm,8.0mm,10.0mm,12.0mm.
1x3: 6.2mm,6.5mm,8.6mm,8.74mm,10.8mm.1x3I:12.9mm,8.7mm.
1x7: 9.5(9.53)mm,11.1(11.11)mm,12.7(12.9)mm,15.2(15.24)mm,15.7mm,17.8(17.78)mm,18.9mm,21.6mm. 1x7I:12.7mm,15.20(15.24)mm (1x7)C : 12.7mm,15.20(15.24)mm,18mm.
1x19S(1+9+9):28.6mm,17.8mm,19.3mm,20.3mm,21.8mm,28.6mm,20.3mm,21.8mm,17.8mm,19.3mm,20.3mm,21.8mm.
1x19W(1+6+6/6):28.6mm
Available nominal tensile strength:
1470MPA,1570MPA,1670MPA,1720MPA,1770MPA,1810MPA,1860MPA,1860MPA,1960MPA
